22000 1/4 NPT Valved Acetal Coupling Insert (PLCD24004 NSF)

#NSSP004284

Product Description

22000 1/4 NPT Valved Acetal Coupling Insert (PLCD24004 NSF)

Main Specifications:

  • Material: Acetal
  • Material Finish: Natural
  • Color: White
  • Mounting Option: Thread
  • Temperature Range: -40°F - 180°F (-40°C - 82°C)
  • Seal Options: FDA BUNA-N
  • Valve Spring: 316 Stainless Steel
  • Valve Options: Valved
  • Body Type: Insert
  • Bag Qty: 25

Features – Benefits:

  • CPC thumb latch - One-hand connection and disconnection
  • Integral terminations - Fewer leak points, shorter assemblies, faster installations
  • Clicks when connected - Assurance of a reliable connection
  • Compatible - Mates with LC and PLC12 Series couplings
Read More

Medical (Core) & Thermal Industry

Additional Information

NESPL Code NSSP004284
Manufacturer Code 22000 PLCD24004
Manufacturer CPC Quick Connect & Disconnect Solutions
Type Quick Fittings
