20800 3/8 Hose Barb Valved In-Line Acetal Coupling Body (PLCD17006 NSF)

#NSSP004260

Product Description

20800 3/8 Hose Barb Valved In-Line Acetal Coupling Body  (PLCD17006 NSF)

Main Features:

  • Colder thumb latch
  • Integral terminations
  • Clicks when connected
  • Compatible
  • NSF Certified

Main Benefits:

  • One-hand connection and disconnection
  • Fewer leak points, shorter assemblies, faster installations
  • Assurance of a reliable connection
  • Mates with LC and PLC12 Series couplings

Main Specifications:

  • Material: Acetal
  • Material Finish: Natural
  • Color: White
  • Mounting Option: Free Floating
  • Temperature Range: -40°F - 180°F (-40°C - 82°C)
  • Seal Options: FDA BUNA-N
  • Valve Spring: 316 Stainless Steel
  • Valve Option: Valved
  • Body Type: Body
  • Weight: .021 Ounce
  • Bag Qty: 25
Read More

Medical (Core) & Thermal Industry

Additional Information

NESPL Code NSSP004260
Manufacturer Code 20800 PLCD17006
HSN Code 84818090
Manufacturer CPC Quick Connect & Disconnect Solutions
Type Quick Fittings
