Rescue U.S. MOTORS® 5464 Permanent Split Capacitor Condenser Fan Motor

#NIDECNESPL28

Product Description

Rescue U.S. MOTORS® 5464 Permanent Split Capacitor Condenser Fan Motor, 1/3 - 1/6 hp, 208/230 V, 1.9 - 1 A, 825 Rpm

U.S. MOTORS® Condenser Fan Motor, Permanent Split Capacitor, 1/3 - 1/6 hp, 208/230 V, 1.9 - 1 A, 60 Hz, 1 Phase, 48 Frame, 825 Rpm, 2 Speed, Reversible, Service Factor: 1, Capacitor: 10 - 7.5 uF, 5-5/8 Inch Body Diameter, 10.3 Inch Overall Length, 1/2 Inch Dia x 5 Inch L Shaft, Ball Bearing, Stud Mount, Mounting Position: All Angle, 64.6% Efficiency, 60 deg C, Class F Insulation, Totally Enclosed Air Over

Main Features:

Automatic reset thermal overload protector

Designed for use with 370 V capacitors

Continuous duty

High efficiency design

Special treated rotor for corrosion protection

Main Application:

Commercial and Residential

Main Specifications:

Top of Form

Attribute name	Attribute value
Amperage Rating	1.9 - 1 A
Bearing Type	Ball
Body Diameter	5-5/8 Inch
Capacitor	10 - 7.5 uF
Efficiency	64.6%
Enclosure Type	Totally Enclosed Air-Over
Frame	48
Frequency Rating	60 Hz, 1 Phase
Insulation Type	Class F
Manufacturer	Nidec Motor Corporation
Mounting Position	All Angle
Mounting Type	Stud
Number of Speeds	2
Overall Length	10.3 Inch
Power Rating	1/3 - 1/6 hp
Rotation Type	Reversible
Service Factor	1
Shaft Size	1/2 Inch Dia x 5 Inch L
Speed	825 Rpm
Temperature Rating	60 deg C
Type	Permanent Split Capacitor
Voltage Rating	208/230 V
